Cell Therapies-Engineered Cartilage Tissue-New Horizons

Srinivas Rao K*
Consultant-Orthopaedics, Employees State Insurance Hospital, Sanathnagar, Hyderabad, Andhra Pradesh, India
*Corresponding Author: Srinivas Rao K, Flat no G3, H No. 6-4-519, MIGH Colony, Hyderabad-500 080, India, Tel: 0091-9490190411 Email:

Abstract

Cartilage tissue engineering is required for the repair of injured cartilage and osteoarticular diseases. Since cartilage cells at the site do not grow to form new cartilage cells, therefore, tissue engineered cartilage approaches aim at cultivating chondrocytes in vitro, and to reintroduce the engineered cultured cartilage tissue into the damaged region. In our study, human cartilage cells cultured on novel microcarrier made of ECM (Extracellular matrix) proteins exhibited hyaline cartilage differentiation, cell proliferation and biocompatibility. Engineered cartilage tissue will be a promising method for the treatment of cartilage defects.

Keywords: Extracellular Matrix (ECM); Cartilage; Engineering; Microcarrier

Introduction

Repair of injured cartilage and osteoarticular diseases is a mojor challenge for Orthopedic surgeons. Cartilage injuries among professional and recreational athletes are increasingly encountered and diagnosed and demand a quick return to preinjury level of sporting activities [1].

Current high-field Magnetic Resonance Imaging (MRI) techniques provide a sensitive and reliable diagnostic tool for the evaluation of cartilage and osteochondral injury [2]. In the athlete, untreated articular cartilage defects can represent a careerthreatening injury and create a significant obstacle in returning to full athletic participation. The markedly limited healing potential of articular cartilage often leads to continued deterioration and progressive functional limitations [3]. Because cartilage cells at the site do not grow to form new cartilage cells, cartilage tissue engineering is required for the repair of injured cartilage. Tissueengineered cartilage approaches aim at cultivating chondrocytes in vitro and to reintroduce the engineered cultured cartilage tissue into the damaged region. Our proposed cell therapy besides being useful in repairing traumatic cartilage lesions can also serve as bioenhancement procedure after joint surgeries like ACL (Anterior cruciate ligament) repair, microfractures, and arthroscopic debridement. Bio enhancement with a bioactive scaffold, like our micro carrier can stimulate healing [4]. At present, cartilage injury cases are treated with multiple drilling, abrasion arthroplasty, mosaicplasty, Autologous Chondrocyte Implantation (ACI), and Matrix-Induced ACI (MACI®). Articular cartilage injuries remain a prime target for regenerative techniques such as tissue engineering. In contrast to the surgical techniques mentioned above, which often lead to the formation of fibrous or fibrocartilaginous tissue, tissue engineering aims at fully restoring the complex structure and properties of the original articular cartilage by using the chondrogenic potential of transplanted cells [5]. MACI® by Genzyme Corporation is proven for cartilage trauma. Collagen I and collagen III are used for MACI® that provide Extracellular Matrix (ECM) environment and hence potentially useful.

Methods

I propose two novel and hypothetical variation of MACI for cartilage injuries and Oseoarthritis. In first approach, autologous chondrocyte are cultured on ECM microcarrier and transplanted. Chondrocytephe-notype can be preserved during culture expansion [6]. In the second approach, autologous Mesenchymal Stem Cells (MSCs) are cultured on ECM microcarrier and differentiated into hyaline cartilage and used for transplantation. Bone marrow has been shown as a possible source of Multipotent Stem Cells (MSCs) with chondrogenic potential [7]. MSCs seeded in hydrogel composites can improve cartilage repair [8]. Effective chondrogenesis can be achieved by directing the MSCs toward chondrocyte lineage [9]. Both approaches have high degree of feasibility as per the published literature. In the last decades, a wide number of researchers/clinicians involved in tissue engineering field published several works about the possibility to induce a tissue regeneration guided by the use of biomaterials [10] like our ECM microcarrier. In our study primary chondrocytes were isolated from discarded human cartilage during joint replacement surgeries. The patient’s consent was taken for the study. The cartilage cells are isolated after enzyme digestion and are cultured on ECM particle (microcarrier) in spinner bottle set up for required period. Similarly, MSCs isolated from bone marrowconcentrates are differentiated into chondrocytes and expanded on ECM microcarrier. The ECM carrier laden with cells is then transplanted in nude mice for study of collagen and GAG expression. In vivo, cartilage matrix formation can be assessed by histology after subcutaneous transplantation of chondrocyteseeded scaffolds in immuno compromised mice [11]. The principle of porous microcarrier culture of human or animal cells is described with help of (Figure 1 and 2).

cell-science-therapy-porous-microcarrier

Figure 1: Principle of porous microcarrier culture of human cartilage cells.

cell-science-therapy-Cellular-Matrix

Figure 2: Extra Cellular Matrix (ECM) microcarrier.

Results

The studies on the construction of engineered cartilage tissue on a ECM composite have high degree of feasibility. The cell attachment ratio to our novel microcarrier, proliferation, and extracellular matrix proteins secretion are superior and reproducible. They have appropriate mechanical and structural properties for clinical applications. The Scanning electron microscope (Figure 3 and 4) and confocal fluoroscope examinations showed that the ECM microcarrier has a regular interconnected porous structure.

cell-science-therapy-Cartilage-cell

Figure 3: Cartilage cell growing on ECM particle.

cell-science-therapy-Ectopic-Implant

Figure 4: Ectopic Implant of Human cartilage cells on nude mice.

The novel ECM microcarrier is effective in engineered chondrocyte culture. The cell viability test (WST-1 assay), cell toxicity (lactate dehydrogenase assay), cell survival rate, extracellular matrix protein production (glycosaminoglycans contents), cell proliferation (DNA quantification), and gene expression (real-time PCR) all revealed good results for chondrocyte culture (Figure 5). The chondrocytes can maintain normal phenotypes, highly express aggrecan and type II collagen, and secrete a great deal of extracellular matrix when seeded in our novel microcarrier. This study demonstrated that a highly organized “Sol-cell”can be prepared with an ECM microcarrier device which is effective in engineering cartilage tissue.

cell-science-therapy-Human-Cartilage

Figure 5: Human Cartilage cell cultured on ECM and stained with safranin O.

Conclusion

The engineered cartilage tissue will be a promising method for the treatment of cartilage defects. The downsides associated with present treatment regimens like multiple drilling, abrasion arthroplasty, mosaicplasty and joint replacement can be addressed with our novel, fluidic yet robust cartilage engineering to overcome the limitations that currently exist, amultidisciplinary field, in which bioengineering and medicine based on integrative approaches using scaffolds, cell populations from different sources, growth factors, and nanomedicine should emerge [12].

References

  1. Kannus P, Natri A (1997) Etiology and pathophysiology of tendon ruptures in sports. Scand J Med Sci Sports 7: 107-112.
  2. Gallo RA, Mosher TJ (2013) Imaging of cartilage and osteochondral injuries: a case-based review. Clin Sports Med 32: 477-505.
  3. Kane P, Frederick R, Tucker B, Dodson CC, Anderson JA, et al. (2013) Surgical restoration/repair of articular cartilage injuries in athletes. Phys Sportsmed 41: 75-86.
  4. Murray MM, Fleming BC (2013) Use of a bioactive scaffold to stimulate anterior cruciate ligament healing also minimizes posttraumatic osteoarthritis after surgery. Am J Sports Med 41: 1762-1770.
  5. Berninger MT, Wexel G, Rummeny EJ, Imhoff AB, Anton M, et al. (2013) Matrix-assisted autologous chondrocyte transplantation for remodeling and repair of chondral defects in a rabbit model. J Vis Exp : e4422.
  6. Heywood HK, Nalesso G, Lee DA, Dell'accio F (2014) Culture expansion in low-glucose conditions preserves chondrocyte differentiation and enhances their subsequent capacity to form cartilage tissue in three-dimensional culture. Biores Open Access 3: 9-18.
  7. Gobbi A, Karnatzikos G, Sankineani SR (2014) One-step surgery with multipotent stem cells for the treatment of large full-thickness chondral defects of the knee. Am J Sports Med 42: 648-657.
  8. Dashtdar H, Murali MR, Abbas AA, Suhaeb AM, Selvaratnam L, et al. (2013) PVA-chitosan composite hydrogel versus alginate beads as a potential mesenchymal stem cell carrier for the treatment of focal cartilage defects. Knee Surg Sports Traumatol Arthrosc .
  9. Liao J, Hu N, Zhou N, Lin L, Zhao C, et al. (2014) Sox9 Potentiates BMP2-Induced Chondrogenic Differentiation and Inhibits BMP2-Induced Osteogenic Differentiation. PLoS One 9: e89025.
  10. Viti F, Scaglione S, Orro A, Milanesi L (2014) Guidelines for managing data and processes in bone and cartilage tissue engineering. BMC Bioinformatics 15 Suppl 1: S14.
  11. Kreuz PC, Gentili C, Samans B, Martinelli D, Krüger JP, et al. (2013) Scaffold-assisted cartilage tissue engineering using infant chondrocytes from human hip cartilage. Osteoarthritis Cartilage 21: 1997-2005.
  12. Salgado AJ, Oliveira JM, Martins A, Teixeira FG, Silva NA, et al. (2013) Tissue engineering and regenerative medicine: past, present, and future. Int Rev Neurobiol 108: 1-33.
Citation: Srinivas Rao K (2014) Cell Therapies-Engineered Cartilage Tissue-New Horizons. J Cell Sci Ther 5:160.

Copyright: © 2014 Srinivas Rao K. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
