A polyvalent amphoteric flushing fluid (Diphoterine^® solution) has been utilized for a number of years for decontamination of eye and skin chemical splashes, mainly in industrial settings. Application of this flushing fluid as soon as possible after the chemical splash at the accident site can prevent or limit the consequences.

Recently, a number of emergency departments have begun using this amphoteric flushing fluid in either the pre-hospital or hospital settings (use by the mobile emergency and intensive care services (SMUR) or in accident and emergency departments). In these circumstances, use of this solution may be more delayed than in industrial settings.

A retrospective multicenter case series of patients with chemical splash exposures decontaminated with Diphoterine^® was assembled from the following hospital emergency departments and pre-hospital services for the years 2013 to 2016:

• Emergency Department, Belfort Hospital (France)

• Emergency Department, Montbéliard Hospital (France)

• Emergency Department, Evreux Hospital (France)

• Emergency Department, Lyon Saint-Joseph-Saint-Luc Hospital (France)

• Emergency Department, Liege Teaching Hospital (Belgium)

• Emergency Department, Saint-Dié Hospital (France)

• Medical Department, Departmental Fire and Rescue Service, Doubs (France)

Thirty-four patients with chemical splash exposures presenting to the above emergency services were included. The following data were retrieved from each patient’s medical records and recorded: age, gender, exposure circumstances, chemical nature and pH, type of exposure, initial clinical symptoms and signs, clinical symptoms and signs after Diphoterine^® decontamination, pain assessment before, during, and after Diphoterine^® flushing using a Visual Analog Scale (VAS; 0-10), time interval between exposure and beginning flushing, and consulting specialists’ conclusions.

The Wilcoxon Rank Sum Test was utilized to compare the VAS pain level before and after Diphoterine^® with p<0.05 considered statistically significant.

The amphoteric flushing solution (Diphoterine^®) was used in compliance with the following protocols:

For Eye Splashes:

• Use of a 500 mL container of Diphoterine^® solution;

• A rapid and initial VAS pain assessment was conducted before flushing of each involved eye with 500 mL of Dipihoterine^® solution;

• VAS pain intensity was assessed during and after flushing;

• Afterwards, rinsing with 500 mL of normal saline was done to prevent dry-eye syndrome because of the hypertonicity of Diphoterine^® solution;

• Then, consultation with an ophthalmologist. (See Figure 1: Protocol for use in the event of eye splashes)

Figure 1: Protocol for use in the event of a chemical eye splash.

For Skin Splashes:

• Use of a 200 mL container of Diphoterine^® solution;

• A 200 mL Diphoterine^® container enables decontamination of

• ~9% of the Total Body Surface Area (TBSA) of an adult patient;

• A rapid initial assessment of the VAS pain level was done before flushing.

• At the conclusion of flushing, the VAS pain level was again assessed;

• Then, a burn specialist’s opinion was obtained. (See Figure 2: Protocol for use in the event of skin splashes.)

Figure 2: Protocol for use in the event of a skin splash.

Thirty-four patients were included in the retrospective study. Details of each case described by exposure circumstances (isolated eye lesions, isolated skin lesions, mixed eye and skin lesions, oral lesions) are shown in Tables 1a-1d. The median age of the patients was 37 years (IQR 25-45) and the male/female gender ratio was 61.30/38.70.

Table 1a: Presentation of the isolated eye lesions.

Table 1b: Presentation of the isolated skin lesions.

Table 1c: Presentation of the mixed lesions (skin and eyes).

Table 1d: Presentation of the Oral lesions.

In 58.8% of cases, the chemical exposure occurred in an industrial setting. In 29.4%, exposure was in a domestic setting, and in 5.9% of cases exposure occurred in an educational setting. In 5.9% of cases, the chemical exposure was due to deliberate assault.

There were 21 isolated ocular injuries (9 bilateral; 12 unilateral), 8 isolated skin injuries, 4 mixed eye and skin injuries, and 1 oral exposure. Involved chemicals were basic substances (11 cases), acidic substances (11 cases), an oxidizer (1 case), solvents (2 cases), and miscellaneous chemical substances (9 cases; acrylic coating, lacrimating agent, etc.).

Among the 25 isolated or mixed ocular injuries, the following signs and symptoms were noted: eye pain (18 cases), blepharospasm (4 cases; see Figure 3 for an example secondary to latex of Euphorbia lathyris exposure), conjunctival hyperemia (15 cases), palpebral edema (2 cases), excessive tearing (1 case), and blurred vision (7 cases). Among the 8 isolated skin injuries, there was 1 case with a deep necrotic lesion and 7 cases of superficial lesions, erythema, or phlyctenae.

Figure 3: Skin and Eye lesions with latex of Euphorbia Lathyris (Case No.1).

Only 1 case of an oral burn due to accidental ingestion of ammonia stored in an unlabeled bottle was noted. The patient immediately expectorated the ammonia. The Tongue lesion before and after Diphoterine^® rinsing repeated 5 times as a mouthwash and expectorated is shown in Figures 4 and 5.

Figure 4: 20h15: Before the mouth washing with Diphoterine^®.

Figure 5: 20h45: After 5 mouth washing with Diphoterine^®.

Initial and final pain level assessment by VAS

The initial pain intensity ranged from 3 to 10 on the VAS. The initial median VAS score before Diphoterine^® eye or skin flushing was 7 (IQR: 4-9). The final median VAS pain intensity score was 1 (IQR: 0-3). Thus, the difference between before-flushing and after-flushing with Diphoterine^® was significant (Wilcoxon Rank Sum Test; p<0.0001).

The time interval between exposure and Diphoterine^® solution eye and/or skin flushing ranged from1-555 minutes (median: 77.5 minutes; IQR: 30-131 minutes).

Clinical signs and symptoms after diphoterine^® eye and/or skin flushing

Ocular signs and symptoms: Resolution of eye pain in 14 cases (final VAS 0 or 1); marked decrease of eye pain in 7 cases (final VAS 2 or 3); persistence of moderate eye pain after Diphoterine^® eye flushing in 3 cases related to chemical lesions induced by a reducing agent (aluminum-magnesium mixture; Case No. 6), “tear gas” (Case No. 18) and glyphosate soda (Case No. 28); Resolution of blepharospasm in the 4 observed cases (Cases Nos. 1, 5, 12, 28); Reduction of initial blurred vision in the 7 observed cases with regression or resolution of initial blurred vision (Cases Nos. 10, 11, 22, 26, 27, 30, 32); Resolution of initial palpebral edema in the 2 observed cases (Cases Nos. 1 and 9)

Cutaneous signs and symptoms: Resolution of all initial skin lesions in the 7 observed cases with superficial lesions (erythema or phlyctenae) by 48 hours post-exposure; In the 1 case of deep necrotic skin injury (Case No.4), there was no local improvement following Diphoterine^® flushing. Recovery followed surgical excision and skin grafting. Of note, Diphoterine^® flushing was quite delayed after exposure.

Oral signs and symptoms: In the only case of mouth exposure (to ammonia; Case No. 21), after 5 repeated Diphoterine^® mouthwashes followed by expectoration (no swallowing), a reduction of the chemical injury was noted (Figures 4 and 5). On the following day, the patient was pain free and had no loss of taste sensation.

Results of ophthalmology specialist consultations: No lesions were noted in 12 patients; Six patients had minimal eye findings (moderate conjunctival lesions which resolved in a few days with standard eye drop treatment); One patient (Case No. 5) had a superficial ulceration of the cornea.

It is generally accepted that decontamination of eye or skin chemical splashes should be done as soon as possible after exposure. While potable water as the flushing fluid has been utilized for a very long time, it is perhaps currently not the best option [1]. Diphoterine^® is a polyvalent amphoteric solution for flushing splashed chemicals off the skin or surface of the eyes. It has been used efficaciously for a number of years in industrial settings [2-5]. In the European Union, Diphoterine^® solution is a Class II medical device. It is not irritating to the eyes or skin, is not sensitizing in guinea pigs or humans, is nontoxic (rat oral/dermal LD50 >2,000 mg/kg) and is not mutagenic in the Ames test [1,6].

Diphoterine^® solution has multiple methods of action

• As an aqueous solution, it flushes a large portion of the splashed chemical substance from the surface of the skin or eyes through mechanical entrainment and dilution;

• As an hypertonic solution, it limits penetration of the splashed chemical substance into the deep tissue layers of the skin or eyes by creating an osmotic pressure gradient;

• As an amphoteric solution (able to bind opposing chemical groups such as acids/bases or oxidizing/reducing agents), it halts the aggressive action of corrosive or irritant chemical substances.

Comparative studies have demonstrated the efficacy of Diphoterine^® solution. Gerard et al. [7] compared the action of Diphoterine^® solution and normal saline in vivo in the context of ammonium hydroxide eye injuries. These authors found a lack of stromal edema when Diphoterine^® solution was used and its presence when flushing was with normal saline. This finding is supported by the difference of osmotic pressure between the two flushing fluids (respectively ~800 mosmols/kg for Diphoterine^® solution versus 280 mosmols/kg for normal saline, while the osmotic pressure of the cornea is 420 mosmols/kg). As a biochemical rationale, the pH curve was decreased during flushing with Diphoterine^® solution.

In a 2002 review, Hall et al. [1] showed that Diphoterine^® solution was more efficacious than water in various industrial studies. Nehles et al. [4] found that when workplace corrosive substances eye and skin splashes were flushed with Diphoterine^®, there was no need for medical treatment other than decontamination, and there were no sequelae and no lost work time.

Cavallini and Casati [8] and Cavallini et al. [9] investigated wound healing and concentrations of ß-endorphin, Substance P, and interleukin IL-6 in a rat in vivo study of concentrated hydrochloric acid skin injury flushed with either Diphoterine^® solution, normal saline, or calcium gluconate solution. In the Diphoterine^® group versus the normal saline and calcium gluconate solution groups, the following were observed:

• A more important decrease in lesion size in the Diphoterine^® solution group;

• Significant beneficial changes in biological markers of pain in the Diphoterine^® solution group: a significant decrease in Substance P concentration at 48 h (p<0.05) and a significant increase in ßendorphin at 7 days (p<0.05);

• A significant decrease in inflammation as shown by decreased IL-6 concentrations at 48 h (p<0.05) and enhanced tissue repair.

Merle et al. [10,11] conducted a clinical study of 66 patients with deliberate assault eye splashes with a base chemical substance (ammonium hydroxide; Alkali^®) in Martinique. These authors reported that, compared to normal saline flushing, Diphoterine^® solution was more efficacious for decreasing the time to corneal re-epithelization in patients with Roper-Hall scale Grade I and II lesions and seemed to be more suitable for emergent flushing of corrosive chemical substance exposed eyes. Schrage et al. [12] considered the pathophysiology of chemical ocular lesions and compared various eyewash solutions. Diphoterine^® appeared to be the best option.

Ioannidis et al. [13] reported the case of a 76-year-old man with eye injury due to exposure to the latex of the Euphorbia lathyris plant. Despite flushing with 8 liters of normal saline followed by treatment with dexamethasone and cicatrizing eye drops, the patient developed a corneal ulcer and severe pain which necessitated a 3-day hospitalization.

This clinical course is in sharp contract to Case No.1 reported here; a 59-year-old man who developed facial skin injuries, eye injuries, and severe pain 4 hours after handling the latex of this same plant. Euphorbia lathyris is a plant used by gardeners; in particular the cut stalks are inserted into mole burrows. The latex from the cut stalks has alkylating and base properties (pH=9) and also contains protease enzymes which repel moles.

After exposure at home, the patient took 10 mg of morphine (already in his possession for the treatment of fibromyalgia) and performed an eye wash with Dacroserum^® solution which did not alleviate the pain. During the initial examination in the hospital emergency department, the patient had blepharospasm, facial lesions, and ocular pain which was scored as 8/10 on the VAS, a well as persistence of blepharospasm. Eye flushing with normal saline resulted in an increase in ocular pain (10/10 on the VAS). Flushing with Diphoterine^® solution (250 mL for each eye) resulted in a decrease of ocular pain (6/10 on the VAS) and resolution of blepharospasm after 15 minutes (Figure 3). After 55 minutes, ocular pain had completely resolved. Ophthalmological examination a few hours later showed only a mild conjunctival lesion. As compared to the case reported by Ioannidis et al. [13], flushing with Diphoterine^® solution resulted in a less severe lesion and rapid pain relief.

Donoghue [5] compared the efficacy of Diphoterine^® solution with that of water for decontamination of alkaline chemical splashes in a clinical study involving 180 workers. In the group treated with Diphoterine^® solution, there were no signs of lesions in 52.9% of cases versus 21.4% of cases flushed with water. Moreover, grade III and IV lesions were significantly less numerous in the Diphoterine^® solution first group (7.9 vs. 23.8%; p<0.001).

Zack-Williams et al. [14] published a 2-year comparative evaluation study. There was a significant change in the wound pH pre- and postflushing with Diphoterine^® solution compared to water flushing (pH change of 1.076 versus 0.4; p<0.05). There were no significant differences in time to healing, length of hospital stay or need for surgery. Based on the retrospective case series presented here, Diphoterine^® solution could be valuable for flushing of corrosive and irritant chemical splashes in the hospital and pre-hospital settings.

Bvrar [15] published a comparative study of CS “tear gas” exposures in Slovenian police officers flushed with Diphoterine^® solution versus no flushing. The policemen refused to compare Diphoterine^® solution with water flushing because of increased pain when CS exposures were flushed with water. Six policemen were exposed to CS only. A second group of 8 policemen sprayed their faces with Diphoterine^® solution before CS exposure and a third group of 8 policemen sprayed their faces with Diphoterine^® solution after exposure. The time between exiting the CS cloud and arriving at the “ready for action” checkpoint was measured. Facial pain both inside the CS cloud and at the checkpoint was assessed using a 0-10 visual analog scale (VAS).

The pain level inside the CS cloud was significantly lower in the group that pre-treated with Diphoterine^® solution (5.6 ± 1.1; p=0.1) versus the CS only group (9.7 ± 0.5). In the post-CS-exposure treatment group, it was similar (9.1 ± 0.4). The time interval between CS exposure and arrival at the checkpoint was significantly shorter in the Diphoterine^® solution pre-treatment group (1.26 ± 0.44 minutes) than in the CS only group (2.28 ± 0.25 minutes; p=0.04) and in the post-exposure treatment group (2.30 ± 0.48 minutes; p=0.02) where it was not different. The residual pain at the checkpoint in the Diphoterine^® pre-CS-exposure (1.1 ± 0.4) and post-exposure (1.4 ± 0.7) groups was similar, with significantly less pain than in the CS only group (2.3 ± 0.5; p=0.02). In this study, post-CS-exposure decontamination with Diphoterine^® solution reduced facial pain whereas pre-CS-exposure treatment reduced both pain and recovery time [15]. These findings are in substantial agreement with those reported in French gendarmes by Viala et al. [16].

Lynn et al. [17] published an independent systematic review of the safety and efficacy of Diphoterine^® solution compared to water and normal saline for the decontamination of ocular and cutaneous chemical burns in humans. All studies published in peer-reviewed journals up to May 2016 were eligible for consideration. Such published data must have included Diphoterine^® solution for decontamination of eye and/or skin chemical splashes as well as meeting other specified criteria. Acceptable studies had to use either a quantitative (e.g., number of lost workdays) or qualitative (e.g., level of erythema) approach when determining cutaneous and/or ocular lesion outcomes. These authors concluded that, despite a relatively small number of published studies, Diphoterine^® solution is safe and highly efficacious in improving healing times, healing sequelae, and pain management of chemical skin and eye injuries in humans. Outcomes are significantly improved as compared to water or normal saline decontamination. These authors concluded:

“We recommend this product be readily available to emergency responders and companies that expose their employees to hazardous chemical substances in order to improve healing sequelae, pain management, and lost work days from these types of burns” [17].

Overall, Diphoterine^® solution limits the action of the splashed chemical substance on the tissues. Through its physical actions, it removes the chemical substance in contact with the tissues (mechanical and osmotic actions). In addition, flushing with Diphoterine^® solution enables the tissues to return to a physiologically acceptable pH. Lesion formation is thus halted. Since the tissue is no longer under aggression and in a physiologically acceptable environment, pain and inflammation decrease. The published studies reviewed show the same mechanisms, during and after flushing with Diphoterine^® solution, as evidenced by decrease in pain and reduction of sequelae.

The majority of the cases reported here showed symptomatic improvement following Diphoterine^® solution flushing. Absorption of the splashed chemical substance into the tissues and resultant cell damage are halted by effective flushing with Diphoterine^® solution.

Eye and skin chemical lesions account for ~4% of all burn cases attending emergency departments. The context is often a domestic accident rather than an occupational exposure. The small number of chemical lesions resulting from occupational accidents observed in the hospital might be explained by the use of the polyvalent, amphoteric Diphoterine^® solution as an emergency decontamination measure in workplace settings. Rapid use of Diphoterine^® solution enables a reduction in the duration of tissue chemical exposure and hence a reduction in the lesions induced.

Both in vitro and in vivo , Diphoterine^® solution has been shown to be effective on eye, skin and mucous membrane chemical injuries. For the best results, Diphoterine^® solution flushing should begin as soon as possible after the chemical splash occurs in order to prevent or lessen lesion development. As more data are accumulated, the efficacy of Diphoterine^® solution should become more apparent to pre-hospital responder organizations and emergency departments.

AHH is a paid consultant to Laboratoire Prevor, Valmondois, France, manufacturer of Diphoterine^®. All other authors report no conflicts of interest.
